Honda CB750A Hondamatic

.

Make Model

Honda CB750A Hondamatic

Year

1976

Engine

Four stroke, transverse four cylinder, SOHC, 2 valve per cylinder.

Capacity

736 cc / 44.9 cu-in
Bore x Stroke 61 х 63 mm
Cooling System Air cooled
Compression Ratio 9.2:1

Induction

4x 28mm keihin carburetors

Ignition

Battery induction coil
Starting Electric

Max Power

50 kW / 67 hp @ 8000 rpm

Max Torque

44 lb-ft / 60 Nm @ 7000 rpm

Transmission

2 Speed
Final Drive Chain
Frame Painted steel

Front Suspension

Telehydraulic forks

Rear Suspension

Swingarm with dual shocks.

Front Brakes

Single 296mm disc

Rear Brakes

Single 296mm disc

Front Tyre

3.25-19

Rear Tyre

4.00-18
Rake  62.5°
Trail 115 mm / 4.5 in
Wheelbase 1480 mm / 58.3 in

Dry Weight

245 kg / 540.1 lbs

Fuel Capacity

19.5 Litres /

Consumption Average

15.6 km;/lit

Standing ¼ Mile

15.8 sec

Top Speed

158 km/h / 98 mph
.
