SYM Jet4 50R Naked







Make Model

SYM Jet4 50R Naked

Year

2014

Engine

Single cylinder, 4-stroke, SOHC

Capacity

49.5 cc / 3.0 cub in.
Bore and Stroke 39 mm / 41.4 mm
Cooling System Air cooled
Compression Ratio 12.2:1
Engine Oil Capacity 0.85 L / 1.8 US pints
Transmission Oil Capacity 0.11 L / 0.23 US pints
Lubrication Dry sump
Exhaust Single

Fuel System

Carburetor (CV)

Induction

Electronic

Ignition

CDI
Spark Plug A7RC
Battery 12V 6 Ah
Starting Electric & kick

Max Power

2.35 kW / 3.2 hp @ 8500 rpm

Max Torque

3.1 Nm / 0.32 kgf-m / 2.18 ft/lbs @ 6500 rpm
Clutch Centrifugal

Transmission

CVT
Final Drive Belt
Frame Steel, monocuna split steel tube

Front Suspension

Telescopic fork

Front Wheel Travel

70 mm / 2.8 in.

Rear Suspension

Twin sided swing arm

Rear Wheel Travel

68 mm / 2.7 in.

Front Brakes

Hydraulic disc, 226 mm

Rear Brakes

Drum, 110 mm
Wheels Aluminium

Front Tyre

120/60-13 tubeless

Rear Tyre

130/70-12 tubeless

Dimensions

Length:  1900 mm / 74.8 in.

Width:      655 mm / 25.8 in.

Height:   1040 mm / 40.9 in.

Wheelbase 1320 mm / 52.0 in.
Seat Height 775 mm / 30.5 in.

Dry Weight

98 kg / 216 lbs

Wet Weight

109 kg / 240 lbs

Fuel Capacity

5.2 L / 1.4 US gal

Average Fuel Consumption

2.1 L/100km / 67 km/l 110 US mpg
Top Speed 60 km/h / 37 mph
Colours Black, Red, Yellow, Light blue





Designed for a younger, sportier look, SYM launches R 50cc version of Jet 4, a scooter with air-cooled engine which has the same qualities of his older brother valve engine, but with lower weight: 98 kgs.

Combined with practical details such as flatbed, lockable glover bos, the front brake disc with large profile, more space under the seat and rear grill racks with integrated handles, make the Jet 4 50cc R scooter 100 % urban - also thanks to its wheels 13" front and 12″ rear, and suspension that provides an optimal combination of stability, agility and comfort.
