BMW F 800GS



Make Model

BMW F 800GS

Year

2024

Engine

Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder

Capacity

895 cc / 54.6 cu-in

Bore x Stroke

86 x 77 mm

Compression Ratio

13.1:1

Cooling System

Liquid cooled
Emission Closed-loop 3-way catalytic converter, emission standard EU-5

Induction

Electronic injection

Ignition

Electronic
Battery 12 V / 9 Ah, maintenance-free

Starting

Electric

Max Power

64 kW / 87hp @ 6750 rpm

Max Torque

91 Nm / 67.1 lb-ft @ 6750 rpm

Clutch

Multiple-disc wet clutch (anti hopping), mechanically operated

Transmission

Claw-shift 6-speed gearbox integrated in crankcase

Final Drive

Endless O-ring chain with shock damping in rear wheel hub
Primary Ratio 1.821
Secondary ratio 2.588
Gear Ratios 1st 2.833, 2nd 2.067, 3rd 1,600, 4th 1.308, 5th 1,103, 6th 0,968

Frame

Bridge-type frame, steel shell construction, load bearing engine

Front Suspension

41mm Upside-down telescopic fork

Front Wheel Travel

170 mm / 6.7 in

Rear Suspension

Aluminium double-sided swinging arm, directly linked WAD central spring strut, spring base and rebound damping adjustable

Rear Wheel Travel

170mm / 6.7 in

Front Brakes

2 x 305mm floating discs, 2-piston floating calipers

Rear Brakes

Single 265mm discs, single-piston floating caliper

ABS System

BMW Motorrad ABS

Wheels

Aluminum cast wheels

Front Wheel

2.5″ x 19″

Rear Wheel

4.25″ x 17”

Front Tyre

110/80 x R19

Rear Tyre

150/70 x R17

Steering Head Angle

63°

Castor

106.1mm / 4.2 in

Dimensions

Length 2296 mm / 90.4in
Width   910m / 35.8 in

Wheelbase

1590 mm / 62.6 in

Seat Height

815 mm / 32.1 in

Wet Weight

227 kg / 500 lbs

Fuel Capacity

15 Litres / 4.0 US gal
.

The new BMW F 900 GS, F 900 GS Adventure and F 800 GS: The new premium mid-range touring enduros provide purist riding fun thanks to even more sophisticated off-road, touring and adventure capabilities. With the new F 900 GS, F 900 GS Adventure and F 800 GS BMW Motorrad is significantly boosting its product range of touring enduros for the mid-range. While the new BMW F 800 GS is the ideal bike, especially for entry-level riders, the BMW F 900 GS Adventure is very well suited for extended adventure trips and for long, demanding tours. All three models have been significantly updated and now offer, among other things, an even higher level of standard equipment in addition to a new drive. The F 900 GS features many far-reaching innovations. The motorcycle’s range of uses has been considerably expanded thanks to its enhanced off-road qualities combined with a drastic weight reduction of 14 kg compared to the predecessor model making it a particularly sporty F Series model.

Drive with advanced 2-cylinder in-line engine with greater capacity, more output and engine drag torque control. In the new F 900 GS, F 900 GS Adventure and F 800 GS the advanced 2-cylinder in-line engine introduced in 2018 with the F 850 GS provides increased riding dynamics. The main reason for this is the increased capacity 895 cc (previously 853 cc). With a 270/450 degree firing interval, the engine generates a particularly emotional sound. In the F 900 GS and F 900 GS Adventure it puts out 77 kW (105 hp) and in the F 800 GS 64 kW (87 hp). In addition to a significant increase in peak power of 10 hp each, the new engines are also characterised by a much fuller torque curve, increased pulling power and faster acceleration.

Two riding modes, ABS Pro and DTC as standard. Riding modes Pro with additional riding modes, riding mode pre-selection and engine drag torque control as optional equipment ex works. The new GS models in the F series already offer the two riding modes "Rain" and "Road" as standard. Dynamic Traction Control DTC, the cornering-optimised ABS Pro and the dynamic brake light. With "riding modes Pro" available as optional equipment ex works, the dynamic qualities of the new F 900 GS, F 900 GS Adventure and F 800 GS can be exploited even more intensively thanks to additional riding modes, the riding mode pre-selection and the engine drag torque control as well as Dynamic Brake Control DBC.

BMW F 900 GS with new, significantly lighter plastic fuel tank and rear section. New, fully adjustable upside-down telescopic forks on the F 900 GS and F 900 GS Adventure. The new F 900 GS, F 900 GS Adventure and F 800 GS rely on a bridge-type frame made of deep-drawn sheet steel parts welded together, which integrates the 2-cylinder in-line engine as a supporting element. The 14.5-litre plastic fuel tank of the new F 900 GS is a completely new development saving 4.5 kg of weight compared to the steel tank of the previous model. The F 900 GS features a completely redesigned rear section which makes it look even more dynamic and save around 2.4 kg of weight. A further 1.7 kg are saved thanks to the rear silencer by Akrapovič. The front wheel on the F 900 GS and F 900 GS Adventure is guided by new, fully adjustable upside-down telescopic forks by Showa.

New Enduro Pro package for the new F 900 GS and Dynamic ESA for the new F 900 GS Adventure and the F 800 GS optionally available ex works. The new F 900 GS can be given even more off-road prowess with the optional equipment ex works Enduro Pro package featuring fully adjustable titanium nitride-coated upside-down telescopic forks, fully adjustable central spring strut as well as handlebar risers and M Endurance chain. The Dynamic ESA (Electronic Suspension Adjustment) electronic suspension is available as optional equipment for the new F 900 GS Adventure and the F 800 GS.

New BMW F 900 GS with ergonomics optimised for off-road use, enduro footrests and aluminium side stand. Optimised adjustable gearshift lever and, on the F 900 GS, a new foot brake lever as well. The increased off-road qualities of the new F 900 GS are expressed by the ergonomic triangle (handlebar - seat - footrests) optimised for off-road use. Lower footrests in combination with the higher handlebar position and the new design of the fuel tank provide clear advantages, especially when riding standing up on rough terrain.

All three new models already offer an adjustable gearshift lever as standard. In conjunction with an optimised bearing and new gearshift lever kinematics, it was also possible to optimise shifting the six-speed transmission even further. The F 900 GS also features a new foot brake lever in a higher position.

New LED headlight on the BMW F 900 GS. All models feature powerful LED light units. Compared to the predecessor model, the LED headlight on the new BMW F 900 GS offers a larger low beam opening angle and thus better illumination directly in front of the motorcycle. The new F 900 GS Adventure and the F 800 GS also feature LED headlights as standard. Furthermore, the turn indicator and control lights of all three models also use LED technology.

Connectivity - unrivalled information diversity and functionality in the form of a large, perfectly readable 6.5-inch TFT display. The new BMW F 900 GS comes as standard with multifunction holder to accommodate navigation devices, action cams and more. The new GS models in the F series already each have a large 6.5-inch TFT display as standard. This applies in particular to the F 800 GS, which previously had an analogue display. Information diversity, quality of presentation and, last but not least, user-friendliness are unrivalled. Phoning, listening to music and navigating while riding is very comfortable. The new BMW F 900 GS is already equipped with a 12 mm holder as standard, which permits action cams or other devices to be mounted. In order to install the BMW Motorrad Connected Ride Navigator or the BMW Motorrad Connected Ride Cradle, the "navigation preparation” option is also required.

BMW F 900 GS with new body dimensions, clear design and colour scheme highlighting its off-road qualities, sportiness and dynamic performance. The new BMW F 900 GS has been completely redesigned and benefits from a dynamic design that signals increased off-road qualities and sportiness, as well as visually highlighting the 14 kg of lowered weight. One of the key points of the new design is the redesigned plastic fuel tank, which allowed for a much slimmer and ergonomically more favourable design with a capacity of only 0.5 litres less than the previous model. New, close-fitting tank side panels, together with a new radiator trim give the new F 900 GS a sleek, sporty and off-road-oriented look. Off-road qualities, sportiness and dynamic performance are also reflected in the entire rear section, which is significantly narrower and more dynamic than the predecessor model. The dynamic appearance of the new F 900 GS is further enhanced by the sporty rear silencer by Akrapovič. The new F 900 GS is available as a basic version in Blackstorm metallic, as a Passion model version in São Paulo yellow solid paint and as a GS Trophy version in Lightwhite solid paint/Racing Blue metallic.

New attractive model variants and colour schemes for the F 900 GS Adventure and F 800 GS. The new F 900 GS Adventure is available as a basic variant in Blackstorm metallic and as a Ride Pro model variant in matt White Aluminium. The new F 800 GS is available as a basic variant in Lightwhite solid paint, as a Sport model variant in Racing Blue and as a Triple Black version in Blackstorm metallic.

The new BMW F 900 GS, F 900 GS Adventure and F 800 GS feature the common highlights:

• Advanced 2-cylinder in-line engine with increased capacity of now 895 cc (previously 853 cc).

• Even higher output and torque: F 900 GS and F 900 GS Adventure with 77 kW (105 hp) at 8,500 rpm and 93 Nm at 6,750 rpm. F 800 GS with 64 kW (87 hp) at 6,750 rpm and 91 Nm at 6,750 rpm.

• 35 kW (48 hp) versions for driving licence class A2 (F 800 GS only).

• High refinement due to two counter-rotating counterbalance shafts.

• Two riding modes "Rain" and "Road" as well as ABS Pro and DTC as standard.

• Ride modes Pro with two additional ride modes as well as Dynamic Brake Control (DBC) and engine drag torque control as optional equipment ex factory.

• B ridge-type style frame.

• Optimised adjustable gearshift lever.

• Sophisticated ergonomics and numerous seat alternatives.

• Practical wind and weather protection.

• Powerful LED lighting units.

• Large, perfectly readable 6.5-inch TFT display with unrivalled information diversity and functionality.

• Intelligent emergency call for quick help in emergency situations as optional equipment ex works.

• Keyless Ride for convenient activation of the locking functions by radio as an optional extra ex works.

• Powerful paintwork and model variants make for unmistakable Enduro characteristics.

• Extensive range of optional equipment, original BMW Motorrad accessories and rider equipment.

The highlights of the new BMW F 900 GS:

• Weight reduced by 14 kg.

• Significantly lighter plastic fuel tank and rear section.

• New body parts.

• New, fully adjustable upside-down telescopic forks.

• Lighter swinging arm.

• Enduro Pro package as optional equipment ex works.

• Sport rear silencer by Akrapovič.

• Ergonomics optimised for off-road use.

• Enduro footrests.

• Heated grips.

• Hand protectors.

• Aluminium side stand.

• New foot brake lever.

• New LED headlight.

• Multifunction holder.

The highlights of the new BMW F 900 GS Adventure:

• New, fully adjustable upside-down telescopic forks.

• LED headlights.

• New side panels.

• Heated grips.

• Aluminium engine guard.

• New Ride Pro optional equipment package.

The highlights of the new BMW F 800 GS:

• TFT display as standard.

• Heated grips

• LED headlight.

• Hand protectors.

• Variocase carrier.
