CCM R 45







Make Model.

CCM R 45

Year

2008

Engine

Four stroke, single cylinder, DOHC, 4 valve (Suzuki DR-Z400)

Capacity

443 cc / 27 cu in
Bore x Stroke

95 x 62.5 mm.

Compression Ratio

11.3:1

Cooling System

Liquid cooled

Lubrication System

Dry sump, oil in frame

Induction

36 mm Dell'Orto carburetor

Ignition

Digital CDI

Starting

Kick

Max Power

29.2 kW / 40 hp @ 8500 rpm

Transmission

5 Speed  /  chain

Final Drive

Chain
Frame Tubular steel, oil in frame

Front Suspension

WP 43 mm upside down fork

Rear Suspension

WP PDS

Front Brakes

Single 320 mm disc

Rear Brakes

Single  260 mm disc

Front Tyre

120/70-17

Rear Tyre

150/70-17
Seat Height 830 mm / 32.7"

Dry Weight

128 kg / 282 lbs

Fuel Capacity

12 L / 3.2 US gal
