Harley Davidson FLHTCU-SE3 Electric Glide Ultra Classic CVO







Make Model

Harley Davidson FLHTCU-SE3 Electric Glide Ultra Classic CVO

Year

2008

Engine

Four stroke, Twin Cam 110™ with integrated oil cooler Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder

Capacity

1802 cc / 109.96 cub in.
Bore x Stroke 101.6 x 111.1 mm
Cooling System Air/Liquid cooled,
Compression Ratio 9.2:1

Induction

Electronic Sequential Port Fuel Injection (ESPFI)

Ignition

Single-fire, non-wasted, map-controlled spark ignition

Starting

Electric

Max Torque

156 Nm / 15.9 kgf-m / 115 ft. lbs @ 3750 rpm
Clutch Multi-plate, wet

Transmissione

6 Speed
Final Drive Belt
Gear Ratio 1st 9.312 9.312 9.030  /  2nd 6.421 6.421 6.226  /  3rd 4.774 4.774  /  4.630   /  4th 3.926 3.926 3.807  /  5th 3.279 3.279 3.179  /  6th 2.790 2.790 2.706
Frame Mild steel, sqaure-section backbone with twin downtubes

Front Suspension

41.3 mm telescopic forks,
Front Wheel Travel 116 mm /

Rear Suspension

Swing Arm Mild steel, rectangular tube sections, stamped junctions; MIG welded,  Lowered, air-adjustable,

Front Brakes

2x 300mm discs 4 piston calipers, ABS Standard

Rear Brakes

Single 300mm disc 4 piston caliper, ABS Standard

Front Tyre

D408 130/80B17 65H

Rear Tyre

D407 180/65B16 81H

Trail 170 mm / 6.6 in
Dimensions Length 2504 mm / 98.6 in.
Width   965 mm / 38 in.
Height 1549 mm / 61 in
Wheelbase 1613 mm / 63.5 in
Seat Height Laden2  706 mm / 27.8 in
Unladen  757 mm / 29.8 in

Wet Weight

 423.2 kg  /  933 lbs

Fuel Capacity

22.7 Litres / 6.0 US  gal

Harley-Davidson Custom Vehicle Operations (CVO) presents the pinnacle of performance and a truly grand getaway for touring riders in 2008 with the FLHTCUSE3 Screamin' Eagle Ultra Classic Electra Glide. Powered by the Twin Cam 110 engine with 6-speed Cruise Drive transmission, the Screamin' Eagle Ultra adds increased fuel range and a new Anti-lock Braking System (ABS) to its impressive array of standard features. Styling updates include a Granite finished powertrain and three new paint schemes, including the 105th Anniversary Crystal Copper and Black Onyx.

Twin Cam 110 Powertrain with new Granite and Chrome finish
Deluxe Ultra King Tour-Pak with premium luggage rack, storage pockets, saddlebag liners and color-matched wrap-around lights
New internally-wired handlebar with electronic throttle control
Chrome four-inch Touring cross-over mufflers with chrome billet end caps
Chrome Touring muffler shields
New Anti-lock Braking System (ABS)
New Brembo front and rear brakes
New six-gallon fuel tank
New dual control heated seat with passenger backrest and complementary adjustable rider backrest
Custom leather dash pad with chrome accent
New Paint:
105th Anniversary Crystal Copper and Black Onyx
Copper Canyon and Stardust Silver
White Frost and Silver Mist
The 105th Anniversary serialized limited-edition model features exclusive color matched medallions, and badges.
Color-matched vented fairing lowers with storage compartments, inner fairing and switch panel and saddlebag filler strips
Advanced Audio System by Harman/Kardon with CD/AM/FM/XM/WB radio receiver, CB/Intercom, amplifier, navigation system and front and rear speakers
New chrome custom CB pod with color-matched insert
Screamin' Eagle SYN3 Synthetic Lubricant

Black high-torque 1.4 kW starter
High-performance clutch with hydraulic actuation
Oil cooler with chrome cover
Chrome voltage regulator
Chrome billet timer cover
Derby covers with color-filled script
Ribbed air cleaner cover with Screamin' Eagle insert
Chrome Nine-Spoke Cast Aluminum wheels
Chrome front custom floating brake rotors
Front brake calipers with CVO inserts
Chrome front axle covers
Chrome fork sliders and chrome upper fork covers
Chrome lower triple tree cover
Chrome custom passing lamp brackets with bullet-style front turn signal
Smoked turn signal lenses with amber bulbs
Electra Glide lightly smoked low windshield and matching adjustable air deflectors
Spun aluminum metal-faced speedo, tachometer and two-inch auxiliary gauges with backlighting
Chrome clutch and brake master cylinders
Chrome switch housings and hand levers
Chrome mirrors
Cruise control
Clear-coated, braided stainless steel front brake and clutch lines
Chrome extended-reach billet brake lever
Chrome billet heel/toe shift levers
Polished stainless steel hex shift linkage
Chrome rider footboard supports and adjustable passenger footboard supports
Stealth Collection rider and passenger footboard pans
Ironside Collection:
Rider and passenger foot board inserts
Heated grips and grip end caps
Brake pedal pad
Shifter pegs
Highway pegs with chrome billet engine guard mounting
Chrome saddlebag cover trim
Chrome valve stem cover caps
Chrome front wheel bearing spacers
Integral garage door opener and receiver
Powered saddlebag and Tour-Pak locks
Carryout saddlebag and Tour-Pak liners
New power locking system with remote/barrel key fob
Harley-Davidson Smart Security System
Indoor storage cover with embroidered CVO logo
Commemorative CVO ignition switch decal, key with box
