Harley Davidson FLHX SE CVO Street Glide







Make Model

Harley Davidson FLHX SE Street Glide CVO

Year

2012

Engine

Four stroke, Twin Cam 110™  Valves Pushrod-operated, overhead valves with hydraulic, self-adjusting lifters; two valves per cylinder

Capacity

1802 cc / 110 cu-in
Bore x Stroke 101.6 x 111.25 mm
Cooling System Air cooled
Compression Ratio 9.2:1

Induction

Electronic Sequential Port Fuel Injection (ESPFI)

Ignition

Single-fire, non-wasted, map-controlled spark ignition

Starting

Electric

Max Torque

156 Nm / 115.1 ft/lb @ 3750 rpm

Transmission

6 Speed
Final Drive Belt
Primary Drive  Chain, 34/46 ratioChain, 34/46 ratio
Gear Ratio 1st 9.594 2nd 6.65 3rd 4.939 4th 3.999 5th 3.407 6th 2.875
Frame Mild steel, square-section backbone with twin downtubes

Front Suspension

41.3 mm telescopic, cartridge-style damping

Rear Suspension

Short, air-adjustable shock

Front Brakes

2x 292mm disc 4 piston caliper

Rear Brakes

Single 292mm disc 4 piston caliper

Front Tyre

MT90B16

Rear Tyre

MU85B16

Rake  26°
Trail 170 mm / 6.7 in
Fork Angle  29.2°
Dimensions Length 2440 mm /  96.2 in.
Wheelbase 1625 mm / 63.5 in
Seat Height Laden  668.0 mm  /  26.3 in
Unladen  693.4 mm  /  27.3 in.
Gross Vehicle Weight Rating 616 kg / 1360 lbs

Dry Weight

367 kg / s810 lbs

Wet Weight

386 kg / 852 lbs

Fuel Capacity

22.7 Litres / 6.0 gal

2012 CVO Street Glide: A high-performance bagger with a fork-mounted bat-wing fairing, the CVO Street Glide has enhanced audio performance with a two-amp/eight-speaker system that includes speakers in the fairing, fairing lowers, and now also in the saddlebag lids. Also new is a low-profile solo touring seat with an embossed insert pattern, detachable passenger pillion and backrest pad, and Diamond Cut Charcoal engine cover inserts and instrument faces. Three new color combinations are available.

The popular Street Glide® model, tuned up, tricked out and packed full of serious power and radical style, gives you the 2012 CVO™ Street Glide®. Loaded with chrome, attitude, amenities, including a custom two-piece solo FL seat and detachable pillion and a dynamic audio system with an integrated iPod and eight custom speakers driven by an additional 400 watts of audio power, the CVO Street Glide boasts a low, lean profile, aggressive look and fresh, custom-styling ideas, making it a true hot-rod bagger.

The CVO Street Glide is built on the innovative Harley-Davidson Touring chassis, based on a single-spar, rigid backbone frame and swingarm developed to withstand the demands of long-haul touring riders.

Harley-Davidson Custom Vehicle OperationsTM takes bagger swagger to a new level with the 2012 CVO Road Glide® Custom, a chrome-drenched, shark-nosed beauty that snarls with Screamin' Eagle authority. This limited-production motorcycle features the most-powerful V-Twin engine offered by Harley-Davidson, an exclusive multi-color paint scheme, a new high-output sound system and a host of fresh custom components. Bombing the boulevard or scorching the highway, the CVO Road Glide® Custom offers an unmatched hot-rod touring experience.


CVO motorcycles are customized using exclusive components and paint treatments combined with premium accessories from the Harley-Davidson Genuine Motor Accessories catalog. The CVO program is often used to introduce new custom components and techniques before they are offered as individual accessories. Harley-Davidson CVO motorcycles are backed by a two-year, unlimited mileage warranty.

Harley-Davidson Custom Vehicle Operations (CVO)TM emphasizes exclusive styling and inspiring performance with four limited-production motorcycle models for 2012. Decked out with bold paint, gleaming chrome, high-output audio and the most-powerful V-Twin engines offered in production Harley-Davidson motorcycles, each CVO model is a rolling object of desire for the discerning motorcyclist.

Each 2012 CVO model is powered by the fuel-injected Twin Cam 110™ V-Twin, the largest-displacement engine offered in a Harley-Davidson motorcycle, rated at up to 122 ft. lbs. of torque. This engine is only available from the factory in CVO models. CVO motorcycles are customized using premium accessories and paint treatments combined with numerous items from the Harley-Davidson Genuine Motor Accessories catalog. The CVO program is often used to introduce new custom components and techniques before they are offered as individual accessories. Harley-Davidson CVO motorcycles are backed by a two-year, unlimited mileage warranty.


Harley-Davidson FLHXSE3 CVO Street Glide Model Highlights

NEW Three exclusive paint schemes:
- Dark Slate/Black Diamond with Phantom Flame graphics
- Hot Citrus/Antique Gunstock with Phantom Flame graphics
- Ruby Red/Typhoon Maroon with Phantom Flame graphics
NEW Custom low profile, solo leather touring seat with an embossed pattern
NEW Matching detachable passenger pillion and passenger backrest pad
NEW High-output amplified audio system with 100 watts of power per channel (400 watts total) and eight custom speakers
NEW New saddlebag lids molded to hold custom 5-inch x 7-inch speakers with bridged tweeters
NEW Diamond Cut, Charcoal faces on speedometer, tachometer and 2-inch gauges
NEW Diamond Cut, Charcoal inserts for timer cover, derby cover and ignition switch
NEW Custom console insert with chrome CVO™ emblem and LED back light
• 19-inch, 7-spoke Mirror Chrome Agitator Custom front wheel and Agitator floating brake rotors with chrome center web
• Side-fill fuel tank with chrome flush-mount
LED fuel gauge and flush-mount cap
• 8GB Apple® iPod nano and iPod® holder
• Color-matched components include: fairing lowers with speaker housings, license plate
light cover, saddlebag latch covers and rear strut covers
• Smoked, 7-inch Electra Glide® wind deflector
• Customer Care package that includes a tool kit, microfiber detail cloth, and H-D® jiffy stand coaster
• Hydraulic rear shocks with hand-adjustable preload
• Twin Cam 110™ granite powder-coated powertrain with 110 Screamin’ Eagle® identifiers on cylinder heads
• Rumble Collection includes grips, rider floorboard inserts, passenger and shifter pegs, and brake pedal pad





2012 Harley-Davidson FLHXSE3 CVO Street Glide Key Features and Benefits

• Anti-Lock Brakes (ABS)
• Electronic Cruise Control
• Smoked turn signal lenses with amber bulbs
• Carry-out saddlebag liners
• Injection-molded, extended saddlebags, full depth with contoured bottoms and increased storage
• Color-matched rear fascia panel incorporates LED stop/turn/tail lights
• Chrome Accessories
- Voltage regulator
- Classic front axle nut covers
- Lower triple tree cover
- Front wheel spacer
- Valve stem cover caps
- Dipstick
- Rider footboard supports
- Passenger footboard supports
• Black high-torque 1.4kW starter
• High-performance clutch with hydraulic actuation
• Harley-Davidson® Smart Security System
