Harley Davidson XLCH 900 Sportster

.

Make Model

Harley Davidson XLH 900 Sportster

Year

1969 - 71

Engine

Four stroke, 45° V-Twin, OHV, 2 valves per cylinder.

Capacity

882 cc / 53.8 cu-in
Bore x Stroke 76.2 x 96.8 mm
Cooling System Air cooled
Compression Ratio 9.0:1
Lubrication Dry sump

Induction

Single 1.625 in., Williston

Ignition

Magnetic
Starting Kick

Max Power

65 hp / 47.4 kW @ 6800 rpm

Max Torque

NA
Clutch Wet, multiple discs, cable operated

Transmission

4 Speed
Final Drive Chain

Front Suspension

Cartridge

Rear Suspension

Dual shocks swinging arm fork

Front Brakes

200mm drum

Rear Brakes

200mm drum

Front Tyre

3.75-19

Rear Tyre

4.25-18

Weight

214 kg / 471.8 lbs

Fuel Capacity

8.5 Litres / 2.2 US gal
.
