MV Agusta 250 Scrambler B







Make Model

MV Agusta 250 Scrambler B

Year

1967 - 69

Engine

 Four stroke, parallel twin, pushrod, 2 valve per cylinder

Capacity

247
Bore x Stroke 53 x 56 mm
Cooling System Air cooled
Compression Ratio 10.0:1
Lubrication Wet sump

Induction

2x 22 mm carburettor

Ignition

Dynamo
Starting Kick

Max Power

19 hp /  @ 7000 rpm
Clutch  Wet multiple plate clutch

Transmission

5 Speed
Final Drive Chain
Frame Single beam tubular and pressed steel

Front Suspension

Telescopic hydraulic fork

Rear Suspension

Swingarm with hydraulic shocks

Front Brakes

180mm Drum

Rear Brakes

150mm Drum

Front Tyre

2.75- 18

Rear Tyre

3.25- 18
Dimensions
Length: 1960 mm / 77.1 in
Width:    620 mm / 24.4 in
Wheelbase 1300 mm / 51.2 in

Dry Weight

142 kg / 313 lbs

Fuel Capacity

13 Litres / 3.4 US gal

Around the refined twin cylinder engine from the road-going version MV developed this Scambler.

It was characterised by an on-off road configuration, with a raised handlebar and raised twin exhaust on the right.
It was a well accepted layout on the US market but was met with skepticism in Italy, also due to the road going tyres.

The colour scheme was silver with a red stripe on the tank.
