MV Agusta 851S Magni







Make Model

MV Agusta 861S Magni

Year

1979

Engine

Four stroke, transverse four cylinders, DOHC, 2 valve per cylinder

Capacity

861 cc / 52.2 cu-in
Cooling System Air cooled
Compression Ratio 10.3:1

Induction

4x 27mm Dell'Orto carb.
Starting Electric

Max Power

71 kW / 92.5 hp @ 10000 rpm
Clutch Multiple disc in oil bath.

Transmission

5 Speed
Final Drive Chain
Frame Tubular steel, welded, double cradle

Front Suspension

38mm Forcelle Italia telescopic forks, preload, rebound damping adjustable.

Rear Suspension

Dual Koni shocks preload adjustable

Front Brakes

2x 280mm discs

Rear Brakes

Single 280mm disc

Front Tyre

110/80 -18

Rear Tyre

150/70 -18

Weight

200 kg / 440 lbs

Fuel Capacity

19 Litres / 5.0 US gal
