MV Agusta Superveloce 800

.

Make Model

MV Agusta Superveloce 800 S

Year

2021

Engine

Four stroke, transverse three cylinder, DOHC with mechanical chain tensioner and DLC tappet, 4 valves per cylinder

Capacity

798 cc / 48.7 cu-in

Bore x Stroke

79 x 54.3 mm

Cooling System

Cooling with separated liquid and oil radiators

Compression Ratio

13.3:1

Emission EURO5

Engine Management System

Integrated ignition - injection system MVICS 2.1 (Motor & Vehicle Integrated Control System) with six injectors Engine control unit Eldor Nemo 2.1, throttle body full ride by wire Mikuni, pencil-coil with ion-sensing technology, control of detonation and misfire. Torque control with four maps. Traction Control with eight levels of intervention

Starting

Electric

Max Power

147 hp / 108 kW @ 13000 rpm

Max Torque

88 Nm / 65 lb-ft @ 10100 rpm

Electronic Quick Shift

MV EAS 3.0 (Electronically Assisted Shift Up & Down)

Clutch

Wet, multi-disc slipper clutch

Transmission

Cassette-style 6-speed, constant mesh

Primary Drive

22/41

Final Drive

Chain

Gear Ratio

1st 13/37  2nd 16/34  3rd 18/32  4th 19/30  5th 21/30  6th 22/29

Final Drive Ratio

17/43

Frame

ALS Steel tubular trellis with aluminium alloy rear swing arm pivot plates

Front Suspension

43mm Marzocchi USD telescopic hydraulic fork with rebound-compression damping and spring preload external and separate adjustment

Front Wheel Travel

125 mm / 4.9 in

Rear Suspension

Progressive Sachs, single shock absorber with rebound and compression damping and spring preload adjustment, single sided swing arm material Aluminium alloy

Rear Wheel Travel

130 mm / 5.1 in

Front Brakes

2x 320mm floating discs, Brembo radial-type monobloc 4 piston calipers

Rear Brakes

Single 220mm disc, Brembo 2 piston caliper

ABS

Continental MK100 with RLM (Rear Wheel Lift-up Mitigation) and with cornering function

Wheels

Aluminium alloy spokes

Front Wheel

3.50 x 17

Rear Wheel

5.50 x 17

Front Tyre

120/70 - ZR 17 M/C (58 W) Pirelli Diablo Rosso Corsa II

Rear Tyre

180/55 - ZR 17 M/C (73 W) Pirelli Diablo Rosso Corsa II

Trail

99 mm / 3.89 in

Dimensions

Length: 2015 mm / 79.92 in
Width:    760 mm / 28.74 in

Wheelbase

1380 mm / 54.33 in

Ground Clarence

120 mm / 4.72 in

Seat Height

830 mm / 32.7 in

Dry Weight

173 kg / 381.4 lbs

Fuel Capacity

16.5 Litres / 4.36 US gal

.

From a press release issued By MV Agusta:

THE NEW SUPERVELOCE FAMILY

SUPERVELOCE S: THE ULTIMATE

The new Superveloce S takes attention to detail to extremes. The new white livery does justice to its timeless lines, designed to cut through the wind. The spoked wheels are a tribute to the bikes of the past, but with all the efficiency and weight of a modern wheel. The brown Alcantara seat adds to the elegance of a bike that sets a benchmark in style and design. The Superveloce S is available with a Racing kit that includes a single-seat tail fairing with brown Alcantara pad, Arrow triple-exit exhaust and related ECU with dedicated mapping.

MECHANICAL AND ELECTRONIC REVOLUTION

An instant classic, the MV Agusta Superveloce is a trendsetter. It combines a contemporary heart and structure with an authentic modern-classic look.

The only racing classic on the market, the Superveloce has quickly become a real milestone for the MV Agusta brand and the post-heritage world in general. MV Agusta has once again created a unique and inimitable blend with this bike. 2021 brings many new features to the Superveloce range, with updated content and a technological shift for an improved riding experience. To achieve this, MV Agusta worked on every aspect of the Superveloce: chassis, engine, gearbox and electronics.

CHASSIS: IN PURSUIT OF PERFECTION

The excellence of the chassis is now the crowning feature of all MV Agusta bikes. But even excellence needs to make constant progress. All the bikes in the Superveloce MY21 range have upgraded chassis architecture with redesigned frame plates that increase torsional and longitudinal stiffness.

EVEN MORE ADVANCED ENGINE

The three-cylinder engine was subject to relentless development. The basic technology remains unchanged, with the characteristic counter-rotating crankshaft (unique for this displacement).

Still with a maximum power of 147 HP (108 kW) at 13,000 rpm, the MV Agusta three-cylinder remains one of the most powerful in its class. Meticulous fine-tuning work by the MV Agusta engineers for the 2021 version – Euro 5 compliant, of course – led to further reductions in internal friction with DLC treatment for the new tappets and new titanium valve guides. They redesigned the entire exhaust system, from the manifold to the silencer, for better control with even more generous torque and power curves at any engine speed. The injectors are also new, capable of handling an additional 0.5 bar of injection pressure. The ECU firmware was also updated, as were the management logic and engine control algorithms, allowing even more precise and refined throttle management. The new twin-flow oil radiator boosts cooling efficiency by more than 5%.

QUICKER AND MORE PRECISE SHIFTING

The clutch also received a major upgrade, with a more robust clutch basket that makes the bike more manageable and quieter. The bi-directional Quick-Shift EAS 3.0 is now in its third generation, with smoother and more precise shifting.

ELECTRONICS: MORE COMPLETE THAN EVER

From the ABS to the controls and ECU firmware, the electronics on the new Superveloce models have seen a significant evolution, thanks in part to the arrival of the IMU inertial platform, an all-Italian project by Milan-based e-Novia, developed specifically for MV Agusta. It detects the bike’s position in space, allowing for extremely accurate management of all the controls based on lean angle.

The ABS, now developed by Continental with specific mappings for MV Agusta, features the cornering function, while TC traction control kicks in more precisely, based on the bike’s angle. The IMU also enables the revamped FLC (front lift control) to execute a controlled wheelie instead of preventing it entirely. Launch Control offers further assistance, intervening on both engine speed and torque. The future of technology before your eyes. All Superveloce models benefit from the 5.5” TFT dashboard, which communicates with the MV Ride App. You can use this to customise every aspect of the bike, including engine settings, and share trips on social media directly from your smartphone. The mirroring function allows for turn-by-turn navigation in addition to route recording and sharing. The handlebar controls have a new joystick for browsing through the various dashboard menus.

THE MAIN NEW FEATURES OF THE SUPERVELOCE MY21

• LOW-FRICTION, EURO 5 COMPLIANT ENGINE

• HIGH-PRESSURE INJECTORS

• REDESIGNED EXHAUST

• NEW INERTIAL PLATFORM

• NEW STRATEGIES LC (LAUNCH CONTROL), FLC (FRONT LIFT CONTROL)

• CONTINENTAL ABS WITH CORNERING FUNCTION

• NEW FRAME PLATES

• NEW QUICK SHIFT SENSOR

• NEW FONT FORK SETTING

• NEW TWIN-FLOW OIL RADIATOR

SUPERVELOCE

The Superveloce is the modern classic by MV Agusta. The gateway to the line, inspired by history while already making history, boasts an updated engine and complete electronics suite, including the inertial platform, which now manages the traction control and cornering ABS more precisely.

CHASSIS

• FRAME PLATES REDESIGNED TO INCREASE TORSIONAL AND LONGITUDINAL STIFFNESS

• NEW TWIN-FLOW OIL RADIATOR WITH MORE THAN 5% EFFICIENCY INCREASE

• NEW SEAT FOAM TO IMPROVE RIDING COMFORT

ADVANTAGES:

COMFORT, STABILITY, AGILITY AND SAFETY. FASTER AND SAFER CHASSIS

ENGINE

• COUNTER-ROTATING CRANKSHAFT

• NEW SINTERED VALVE GUIDES AND DLC COATED TAPPETS TO REDUCE FRICTION

• TITANIUM VALVES

• NEW CRANKSHAFT MAIN BEARINGS, PISTON ROD BEARINGS AND COUNTERSHAFT BEARINGS TO REDUCE FRICTION AND TO INCREASE RELIABILITY

• MODIFIED EXHAUST COLLECTOR TO IMPROVE ENGINE TUNING AND OPTIMISE POWER/TORQUE CURVES

• NEWLY DESIGNED EXHAUST SILENCER

• NEW CLUTCH BASKET OPTIMISED TO IMPROVE ENGAGEMENT

ADVANTAGES:

BETTER OPERATION AND RELIABILITY, IN FULL COMPLIANCE WITH EURO 5 REGULATIONS

ELECTRONICS

• NEW ABS MK100 CONTINENTAL MODULE WITH CORNERING FUNCTION FOR CONSTANT SAFETY EVEN IN CURVES

• NEW INERTIAL PLATFORM

• NEW COLOUR 5.5” TFT DASHBOARD

• MOBISAT TRACKER

• GPS AND BLUETOOTH

• MV RIDE APP

• NAVIGATOR INTEGRATED IN THE DASH-BOARD

• FRONT LIFT CONTROL

• NEW HANDLEBAR CONTROLS WITH LAUNCH CONTROL

• NEW EAS 3.0 ELECTRONIC GEAR SENSOR

• NEW ENGINE MANAGEMENT ALGORITHMS FOR A DIRECT CONNECTION BETWEEN THROTTLE AND REAR WHEEL

• CRUISE CONTROL

ADVANTAGES:

A BETTER FEELING RIDE. THE ADVANCED ELECTRONICS MAKES RIDING EASIER, MORE INTUITIVE AND SAFER
