Suzuki T200

Suzuki T 200 Invader

Make Model	Suzuki T 200 Invader
Year	1967 -
Engine	Two stroke, parallel twin
Capacity	196 cc / 12.0 cu in
Bore x Stroke	50 x 50 mm
Compression Ratio	7.0:1
Cooling System	Air cooled
Lubrication System	Posi-Force lubtication
Exhaust	2-into-2, Power pipe, upswept
Induction	Mikuni VM22SH
Ignition	Battery and coil
Starting	Kick
Spark Plug	B-77HC
Max Power	17.2 kW / 23 hp @ 7500 rpm
Max Torque	22.6 Nm / 2.3 kgf-m / 16.7 lb-ft @ 7000 rpm
Clutch	Wet,multi-plate
Transmission	5-Speed, constant mesh
Final Drive	Chain
Primary Reduction	2.95
Gear Ratios	1 st 2.77 / 2nd 1.72 / 3rd 1.32 / 4th 1.09 / 5th 0.92
Final Reduction	2.64
Frame	Tri-form frame
Front Suspension	Telescopic hydraulic fork
Rear Suspension	Twin, plunger type hydraulic shocks, swingarm
Front Brakes	Drum, internal expanding, leading shoe
Rear Brakes	Drum, internal expanding, leading shoe
Front Tyre	2.75-18
Rear Tyre	2.75-18
Dimensions	Length: 1930 mm / 76.0 in Width: 775 mm / 30.5 in Height: 1030 mm / 40.6 in
Wheelbase	1270 mm / 50.0 in
Ground Clearance	163 mm / 6.4 in
Seat Height	780 mm / 30.7 in
Wet Weight	123 kg / 272 lbs
Oil Capacity	1.6 L / 1.7 US qt / 1.4 Imp qt
Fuel Capacity	12 L / 3.2 US gal / 2.6 Imp gal
Standing ¹/₄ Mile	17.4 sec / 122 km/h / 76 mph
Top Speed (est.)	142 km/h / 88 mph

Suzuki followed up its sensational T20 Super Six with a 200cc version - the T200 Invader. Introduced in 1967, the T200 was styled like its 250cc brother but subtly scaled down as well as having 'only' five gears and a smaller engine. The latter produced 23bhp, six horsepower down on the T20's but this was nevertheless sufficient to propel the 'junior' twin past 80mph. The T200 lasted in production for four years, being dropped from the range at the end of 1971.
