Triumph Bonneville







Make Model.

Triumph Bonneville

Year

2007

Engine

Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder

Capacity

865 cc / 52.8 cu in
Bore x Stroke 90 x 68 mm
Cooling System Air-cooled
Compression Ratio 9.2:1
Lubrication Wet sump
Engine Oil Synthetic, 15W/50

Induction

Multipoint Sequential Fuel injection

Ignition

Digital

Max Power

49 kW / 66 hp @ 7250 rpm

Max Torque

71 Nm / 7.24 kgf-m / 52 ft-lb @ 6000 rpm
Clutch Wet, multi plate

Transmission

5 Speed
Final Drive Chain, X-ring
Frame Tubular steel cradle, swing arm: twin-sided, tubular steel

Front Suspension

41mm Kayaba telescopic forks
Front Wheel Travel 120 mm / 4.7 in

Rear Suspension

Kayaba chrome spring twin shocks with adjustable preload
Rear Wheel Travel 106 mm / 4.17 in

Front Brakes

Single 310 mm disc, 2 piston calipers

Rear Brakes

Single 255 mm disc, 2 piston calipers
Wheels Front 36 Spokes, 19 x 2.5 in
Wheels Rear 36 Spokes, 17 x 3.5 in

Front Tyre

100/90 19

Rear Tyre

130/80 17
Rake 28°
Trail 110 mm / 4.3 in
Dimensions Length 2230 mm / 87.8 in
Width     840 mm / 33.1 in
Height  1100 mm / 43.3 in
Wheelbase 1500 mm / 59.1 in
Seat Height 775 mm / 30.5 in

Dry Weight

205 kg / 451 lbs

Wet Weight

226 kg / 499 lbs

Fuel Capacity

16.6 Litres / 4.4 US gal / 3.7 Imp gal

A true roadster in every sense of the word, the Bonneville matches classic British style to 21st century technology. This pairing of authenticity with modernity has led the Bonneville to become an icon in its own right; world famous designer Paul Smith personally designed a signature series of Bonnies, with accessories to match. Our sixty8 range, which includes hand crafted laptop bags, iPod holders and a series of unique custom-painted tank covers, are all useful and stylish additions.

For 2007 the Bonneville has an increased engine size of 865cc. This latest model also comes with a black engine and polished, lacquered engine covers and a span adjustment clutch lever.

The Bonneville has excellent road manners and great agility in jammed city streets. The Bonneville’s road holding, handling and stopping ability is crisp, composed and confidence inspiring. The braking set-up of single front 310mm disc and 255mm rear, both worked on by powerful twin-piston calipers offers sensitivity and control.

The Bonneville’s a great way to cover the urban landscape and equally at home blatting down a leafy country lane on a Sunday ride out.

Why not go along to your Triumph dealer and test ride a true icon?

AUTHENTICITY WITH MODERNITY

A true roadster in every sense of the word, the Bonneville matches classic British style to 21st century technology. This pairing of authenticity with modernity has led the Bonneville to become an icon in its own right; world famous (and quintessentially British) designer Paul Smith has personally designed a signature series of Bonnies, with accessories to match. Triumph’s own sixty8 range, which includes hand crafted laptop bags, iPod holders and a series of unique custom-painted tank covers, further enhances the Bonneville’s status not only as a motorcycle but also as a cool style statement.

For 2007, the Bonneville receives the following changes:

• Increased engine capacity from 790cc to 865cc
• Black engine with polished and lacquered covers
• Adjustable clutch lever
